ASROCK B760 4xDDR5 4xSATA3 RAID HDMI DP 3xM2 GLAN 2xPCIEx16 WiFi

Manufacturer ASROCK
Memory type Dual Channel DDR5 Memory Technology; 4 x DDR5 DIMM Slots; Supports DDR5 non-ECC, un-buffered memory up to 7200+(OC)*; Max. capacity of system memory: 256GB; Supports Intel® Extreme Memory Profile (XMP) 3.0;
CPUs supported Supports 14th, 13th & 12th Gen Intel® Core™ Processors (LGA1700); Supports Intel® Hybrid Technology; Supports Intel® Turbo Boost Max 3.0 Technology; Supports Intel® Thermal Velocity Boost (TVB); Supports Intel® Adaptive Boost Technology (ABT);
Chipset Intel® B760
Graphics Intel® Xe Graphics Architecture (Gen 12); 1 x HDMI 2.1 TMDS Compatible, supports HDCP 2.3 and max. resolution up to 4K 60Hz; 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz;
Expansion Slots CPU:1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*; Chipset:1 x PCIe 3.0 x16 Slot (PCIE2), supports x4 mode*; 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel® CNVio/CNVio2 (Integrated WiFi/BT); Supports AMD CrossFire™;
Storage CPU:1 x Hyper M.2 Socket (M2_1, Key M), supports type 2242/2260/2280 PCIe Gen4x4 (64 Gb/s) mode*; Chipset:1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*; 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*; 4 x SATA3 6.0 Gb/s Connectors;
I/O 1 x USB 3.2 Gen1 Type-C (Rear); 5 x USB 3.2 Gen1 Type-A (3 Rear, 2 Front); 6 x USB 2.0 (2 Rear, 4 Front); All USB ports support ESD Protection; 2 x Antenna Ports; 1 x PS/2 Mouse/Keyboard Port; 1 x HDMI Port; 1 x DisplayPort 1.4; 1 x USB 3.2 Gen1 Type-C Port; 3 x USB 3.2 Gen1 Type-A Ports; 2 x USB 2.0 Ports; 1 x RJ-45 LAN Port; HD Audio Jacks: Line in / Front Speaker / Microphone;
Connectors 1 x SPI TPM Header; 1 x Chassis Intrusion and Speaker Header; 1 x CPU Fan Connector (4-pin)*; 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**; 4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)***; 1 x 24 pin ATX Power Connector; 1 x 8 pin 12V Power Connector (Hi-Density Power Connector); 1 x Front Panel Audio Connector; 1 x Thunderbolt™ AIC Connector (5-pin) (Supports ASRock Thunderbolt™ 4 AIC Card); 2 x USB 2.0 Headers (Support 4 USB 2.0 ports); 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports); *CPU_FAN1 supports the fan power up to 1A (12W).; **CPU_FAN2/WP supports the fan power up to 2A (24W).; ***CHA_FAN1~4/WP support the fan power up to 2A (24W).; CPU_FAN2/WP and CHA_FAN1~4/WP can auto detect if 3-pin or 4-pin fan is in use.;
Audio 7.1 CH HD Audio (Realtek ALC897 Audio Codec); Nahimic Audio;
LAN 2.5 Gigabit LAN 10/100/1000/2500 Mb/s; Dragon RTL8125BG; Supports Phantom Gaming LAN Software; Smart Auto Adjust Bandwidth Control; Visual User Friendly UI; Visual Network Usage Statistics; Optimized Default Setting for Game, Browser, and Streaming Modes; User Customized Priority Control; Wireless LAN; 802.11ax Wi-Fi 6E Module; Supports IEEE 802.11a/b/g/n/ac/ax; Supports Dual-Band 2x2 with extended 6GHz band support*; 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology; Supports Bluetooth 5.3 + High speed class II; Supports MU-MIMO;
BIOS 128Mb AMI UEFI Legal BIOS with GUI support
Form Factor Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm
OS Microsoft Windows® 10 64-bit / 11 64-bit
Other Software ASRock Motherboard Utility (Phantom Gaming Tuning); ASRock Phantom Gaming LAN Software*; UEFI ASRock EZ Mode; ASRock Full HD UEFI; ASRock My Favorites in UEFI; ASRock Auto Driver Installer; ASRock Instant Flash; ASRock Easy RAID Installer; Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices; Superb Productivity; PCIe Gen5 (Graphics); Dual Channel DDR5; Rock-Solid Durability; 7+1+1 Power Phase, 50A Dr.MOS for VCore+GT Ultrafast Connectivity; 2.5G LAN, 802.11ax Wi-Fi 6E; Module EZ Update; ASRock Auto Driver Installer; EZ Troubleshooter;
Warranty 36 Months
